Agilent E3630A 35W Power Supply

Affordable, clean, reliable, power for your bench top.

Multi-output models
With multiple supplies in a compact unit, the E3620A and E3630A give you excellent performance while saving space on your bench. Both instruments feature tight 0.01 percent line and load regulation and a low normal-mode noise specification of less than 0.35mV to ensure clean power for precision circuitry. With a common-mode current specification of less than 1uA, both multiple-output power supplies minimize power line current injection.

Like the single-output models in the E3600 series, the E3620A and E3630A feature separate digital panel meters so you can monitor voltage and current simultaneously. They also protect your DUT against overload and short-circuit damage. Smooth turn-on and turn-off transitions keep power spikes out of your circuits.

E3630A triple-output power supply
The 35-watt E3630A triple- output power supply provides three dc outputs: 0 to 6 V with a maximum current of 1 to 2.5A and 0 to 20 V and 0 to -20 V with a maximum current of 0.5A. An autotracking feature lets you use one voltage control to adjust the +20 V and -20 V outputs simultaneously. The outputs track each other to within 1 percent, making it easy to adjust the power supply for circuits requiring balanced voltages.

Features:

- 35W triple output
- Constant voltage (CV) and current limit (CL) modes (±20V)
- Constant voltage (CV) and current foldback (CF) modes (+6V)
- Low noise and excellent regulation
- Digital voltage and current meters
- Output tracking
